| project | Optional parameters / description |
|---|---|
| switch combination | 11 1NO1NC、22 2NO2NC |
| Operation type | EZX with lights option; ZX option; KZX key option; EKZX with lights option |
| Operating position | 2 positions (ON-OFF), 3 positions (ON-OFF-ON) |
| Operation type | Retaining type; self-resetting type |
| Light color | Red, yellow, green, white, blue, and no light option. |
| Voltage of the lamp section | AC/DC 6V~220V, other voltages |
| Shell material | Chromium-plated brass (N), stainless steel (S), aluminum alloy (A) |
| project | Parameters/Description |
|---|---|
| Operating ambient temperature | -20~+55℃; requires ventilation and drying when not in use (without sealed casing). |
| Working environment humidity | 45~85% RH, no condensation |
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥1000MΩ |
| Insulation withstand voltage | 1500V (AC 50Hz, 1 minute); 500V (AC 50Hz, 1 minute) |
| Vibration resistance | 50Hz, amplitude approximately 1.2mm |
| Impact resistance | ＞10g |
| Installation dimensions | Mounting hole Φ22mm; |
| Protection level | IP65.IK02 |
| Electrical life | Switching: Over 50,000 cycles |
| Mechanical life | Switching: Over 50,000 cycles |
| Rear configuration | Welding piece 2.8*0.5mm |
| Electrical parameters | 5A, 250V |
| Base material | PBT |
FXB22-11ZX2-------------------------------2-position rotary switch
FXB22-22ZX3-------------------------------3-position rotary switch
FXB22-11EZX2-------------------------------2-position rotary switch with indicator light
FXB22-22EZX3-------------------------------3-position rotary switch with indicator light
FXB22-11KZX2-------------------------------2-position keyless rotary switch
FXB22-22KZX3-------------------------------3-position keyless rotary switch
FXB22-11EKZX2-------------------------------2-position rotary switch with key and indicator light
FXB22-22EKZX3-------------------------------3-position rotary switch with key and indicator light
FXB22-11X2-------------------------------2-position rotary switch
FXB22-22X3-------------------------------3-position rotary switch
FXB22-11EX2-------------------------------2-position rotary switch with indicator light
FXB22-22EX3-------------------------------3-position rotary switch with indicator light
FXB22-11KX2-------------------------------2-position keyless rotary switch
FXB22-22KX3-------------------------------3-position keyless rotary switch
FXB22-11EKX2-------------------------------2-position rotary switch with key and indicator light
FXB22-22EKX3-------------------------------3-position rotary switch with key and indicator light
