| Category | Details |
|---|---|
| Product Features | - Triggered by pressure switch- Service life: 50 million cycles- Mounting dimensions: 16,19,22,25,30mm- Live reset function available- Waterproof rating: IP68/IP69K, with delay function- Applicable in various harsh environments |
| Performance Characteristics | - Max voltage/current rating: 200mA, 24VAC/DC- Switch resistance (ON): 5mΩ max.- Switch resistance (OFF): 10 MΩ min.- Mounting torque: 0.5-1.0N- Operating force: 1-5N- Operating life: 50 million cycles- LED consumption: 10mA (single strip), 20mA (ring strip) |
| General Technical Conditions | - Waterproof performance: IP68/IP69K- Impact resistance: 10-500Hz/10g- Operating temperature: -40℃ to +75℃ |
| Material | - Housing: Electroplated color, stainless steel- Lead wire: 0.22mm diameter, 300mm length (each two wires twisted)- PC terminal: Copper-tin plated |
Detailed information and dimensions can be referred to in the catalog.
